| Model | T192-800 |
| Maximum Deployment Weight | 800kg |
| Maximum Deployment Speed | 220 km/h |
| Ejection System Component Weight | 2.5kg |
| Ejection System Dimensions | Φ79x355mm |
| Parachute Component Weight | 12.5kg |
| Packaging Method | Soft Pack |
| Container Dimensions | 40×14×34cm |
| Total System Weight | 15kg |
| Deployment Time (under Hovering Conditions) | 4s |
| Minimum Deployment Altitude (under Hovering Conditions) | 60m |
| Maximum Deployment Load | 6g |
| Maximum Descent Rate (at 1500 meters standard daytime temperature) | ≤7.5m/s (equivalent to a fall from a height of 2.9 meters) |
| Main Canopy Area | 175㎡ |
| Total Impulse | 700NS |
| Rocket Motor Burn Duration | 1±0.1 s |
| Rocket Activation Method | Manual Activation Flight Control Activation |
| ECU Communication Protocol | CAN \ PWM \ RS-232 |
| ECU Power Input | 12-36v |
| Operating Temperature Range | – 40°C – +60°C |
| Maintenance Interval | 6Years |
| System Service Life | 12 Years |
The T181 Aircraft Parachute Recovery System (APRS) utilizes a Mechanical Activation Rocket to provide essential safety for fixed-wing aircraft in emergency situations. When an aircraft faces significant malfunctions or loss of control, the system slows the descent, helping to stabilize the flight and ensuring a controlled and safe landing.
SkyEagle cargo parachute systems are military-grade systems that facilitate the aerial delivery of bulk cargo. These parachutes are engineered to stabilize and decelerate the load during descent, ensuring a safe and effective delivery from aircraft. Although intended mainly for military operations, such as resupply missions, the cargo parachute system is versatile enough for use in humanitarian aid operations. Its straightforward design allows personnel to quickly deploy the system in the field.
