| Model | T183-1000 |
| Maximum Total Weight | 1000 kg |
| Maximum Deployment Speed | 260 km/h |
| Container Dimensions (mm) | Φ306*797 |
| Total System Weight | 23.1 kg |
| Deployment Time (at 90 km/h level flight) | 6s |
| Minimum Deployment Altitude (at 90 km/h level flight) | 180m |
| Maximum Deployment Load | 6g |
| Maximum Descent Speed (at 1500 m ASL, standard temperature) | ≤7.9m/s (equivalent to a fall from a height of 3.2meters) |
| Closure Device | Yes |
| Parachute Area | 206 ㎡ |
| Packing Cycle | 6 years |
| Activation Method | Manual Activation/Flight Control Activation Autonomous Activation |
| ECU Communication Protocol | CAN \ PWM \ RS-232 |
| ECU Power Input | 12-36v |
| Operating Temperature Range | – 40°C – +60°C |
| Maintenance Intervals | 6 years |
| System Service Life | 12 years |
The T193 Emergency Recovery Parachute System is tailored to fulfill the safety needs of eVTOLs, low-altitude multirotors, and similar aerial vehicles. This state-of-the-art system employs a gas-ejection mechanism for parachute deployment, providing rapid and dependable activation in critical situations. It offers multiple activation modes, including manual operation, flight control system-triggered deployment, and autonomous activation for enhanced operational flexibility.
